Custom MMIC
On February 19th Qorvo acquired Custom MMIC, making it a new member of Qorvo’s Infrastructure Defense Products (IDP) family. Founded in 2006, Custom MMIC has extensive experience developing MMICs at frequencies up to 70 GHz. Custom MMIC adds small signal mmWave expertise and a portfolio of more than 180 standard products including LNAs, mixers, attenuators, phase shifters and switches. Read press release here.
Featured Products
Key Features
- High output power
- Low noise figure
- Pb-free RoHS compliant 5×5 mm SMT package
- Positive gain slope
- Ultra wideband performance
Qorvo’s CMD192C5 is a wideband GaAs MMIC distributed driver amplifier which operates from DC to 20 GHz and is housed in a leadless surface mount (SMT) package. The amplifier delivers greater than 19 dB of gain with a corresponding output 1 dB compression point of +25 dBm and noise figure of 1.9 dB at 10 GHz. The CMD192C5 LNA MMIC is a 50 ohm matched design which eliminates the need for RF port matching. This amplifier is the perfect alternative to higher cost hybrid amplifiers. Key Applications are Electronic Warfare (EW), Radar, Space, Satellite Communications (Satcom), and Test & Measurement.
Key Features
- Ultra-wideband performance
- Positive gain slope
- High output power
- Low noise figure
- Pb-free RoHS compliant 5×5 mm SMT package
Qorvo’s CMD244K5 is a wideband GaAs MMIC distributed driver amplifier which operates from DC to 20 GHz and is housed in a leadless surface mount package. This driver amplifier MMIC delivers greater than 17 dB of gain with a corresponding output 1 dB compression point of +25 dBm, and noise figure of 2.5 dB at 10 GHz. The CMD244K5 is a 50 ohm matched design which eliminates the need for RF port matching. Key Applications are Electronic Warfare (EW), Radar, Space, Satellite Communications (Satcom), and Test & Measurement.
Key Features
- Ultra wideband performance
- High linearity
- High output power
- Excellent return losses
- Pb-free RoHS compliant 5×5 mm QFN package
Qorvo’s CMD249P5 is wideband GaAs MMIC distributed power amplifier housed in a leadless 5×5 mm plastic surface mount package. The amplifier delivers 12.5 dB of gain with a corresponding output 1 dB compression point of +28 dBm and an output IP3 of 39 dBm at 10 GHz. The CMD249P5 is a 50 ohm matched design which eliminates the need for RF port matching. Key Applications are Electronic Warfare (EW), Radar, Space, Satellite Communications (Satcom), and Test & Measurement.
CMD292
Key Features
- Ultra wideband performance
- High linearity
- High output power
- HMC994 replacement
- Small die size
Qorvo’s CMD292 is wideband GaAs MMIC distributed driver amplifier die which operates from DC to 30 GHz. The amplifier delivers 13 dB of gain with a corresponding output 1 dB compression point of +27 dBm and output IP3 of 33 dBm at 15 GHz. The CMD292 is a 50 ohm matched design which eliminates the need for RF port matching. The CMD292 provides a unique positive gain slope, with over 2dB increase over the operating frequency range of DC to 30GHz.
Key Features
- Wide bandwidth
- High linearity
- Low current consumption
- Pb-free RoHS compliant 4×4 mm SMT package
Qorvo’s CMD295C4 is a wideband driver amplifier housed in a leadless surface mount package ideally suited for military, space and communications systems where small size and high linearity are needed. At 10 GHz the device delivers greater than 27 dB of gain with a corresponding output 1 dB compression point of +16 dBm and an output IP3 of 29 dBm. The CMD295C4 is a 50 ohm matched design which eliminates the need for external DC blocks and RF port matching. Key Applications are Electronic Warfare (EW), Radar, Space, Satellite Communications (Satcom), and Test & Measurement.
