Featured Products
Key Features
- Frequency Range: 3.1 – 3.5 GHz
- PSAT: 45 dBm
- Frequency Range: 9 – 11 GHz
- PSAT: 44.5 dBm
Key Applications
- Radar
The QPA0007 is a reconfigurable dual-band MMIC power amplifier operating in both S-Band and X-Band. In S-Band, it provides 32 W saturated power over the 3.1 to 3.5 GHz frequency range. In X-Band, it provides 28 W saturated power from 9 to 11 GHz. The QPA0007 is 100% DC and RF tested to ensure compliance to electrical specifications. Lead free and RoHS compliant.
Key Features
- Frequency Range: 8-12 GHz
- TX PSAT: 40dBm
- RX NF: 2.2dB
Key Applications
- Communications
- Commercial and Military Radar
QPF5010 is a multi-die front-end module (FEM) designed for 8-12 GHz X-Band applications. The FEM integrates T/R switch, limiter, low-noise amplifier, and power amplifier. Transmit power is 10W saturated, receiver noise figure is 2.2dB. Lead free and RoHS compliant.
Key Features
- Frequency Range: 5 – 6 GHz
- PSAT: 50 dBm
Key Applications
- Electronic Warfare
- Radar
Key Features
- Frequency Range: 2.9 – 3.5 GHz
- PSAT: 52 dBm
Key Applications
- Electronic Warfare
- Radar
Qorvo’s QPA3070 is a packaged, high-power S-band amplifier. Covering 2.9 – 3.5 GHz, the QPA3070 provides 52 dBm of saturated output power. QPA3070 is 100% DC and RF tested on-wafer to ensure compliance to electrical specifications. Lead free and RoHS compliant.
Key Features
- Frequency Range: 2 -20 GHz
- Output Power (PIN = 27 dBm): 40 dBm
- PAE (PIN = 27 dBm): 22%
- Small Signal Gain: 19 dB
- Recommended Bias: VD = 22 V, IDQ = 1680 mA
- Package Size: 5 x 5 x 1.455 mm
Key Applications
- Communication Systems
- Electronic Warfare
- Radar
- Test Equipment
Qorvo’s QPA2962 is a wideband power amplifier fabricated on Qorvo’s QGaN15 GaN on SiC process. The QPA2962 operates from 2 to 20 GHz, providing 10 W of saturated power with 13 dB large signal gain and 22 % power-added efficiency at 22 V drain bias. RF ports are matched to 50 Ω, including integrated DC blocking capacitors and a RF choke.
Packaged in a 5 x 5 mm air cavity laminate package, QPA2962 provides designers with a convenient SMT compatible device that delivers a valuable combination of wideband power, gain and efficiency while reducing size and cost. QPA2962 is ideally suited for wideband communications systems, electronic warfare, test instrumentation and radar applications across both military and commercial markets.
QPA2962 is 100% DC and RF tested on-wafer to ensure compliance to electrical specifications. Lead free and RoHS compliant.
View S-Parameters
Key Features
- Frequency Range: 32 - 38 GHz
- PSAT (PIN = 23 dBm): 35 dBm
- PAE (PIN = 23 dBm): 16%
- Small Signal Gain: 19 dB
- Return Loss: 12 dB
- Bias: Pulsed VD = +6 V, IDQ = 2.1 A
- Package Dimensions: 7.0 x 8.0 x 1.465 mm
Key Applications
- Radar
- Satellite Communications
Qorvo’s QPA2575 is a Ka-band power amplifier fabricated on Qorvo’s QPHT15 0.15 um power pHEMT process. The QPA2575 operates from 32 to 38 GHz, providing 3 W of saturated power with 16 % power-added efficiency, and 19 dB small signal gain.
To simplify system integration, the QPA2575 is fully matched to 50 ohms with integrated DC blocking caps on both I/O ports. It is ideally suited to support both commercial and defense related opportunities.
The QPA2575 is 100% DC and RF tested on-wafer to ensure compliance to performance specifications. Lead-free and RoHS compliant
View S-Parameters
View Gerber PCB Layout Files
Key Features
- Frequency Range: 8 – 12 GHz
- Tx Psat: 37 dBm
- Rx NF: 2.2 dB
Key Applications
- Communications
- Commercial and Military Radar
QPF5005 is a multi-die front-end module (FEM) designed for 8 – 12 GHz X-Band applications. The FEM integrates T/R switch, limiter, low-noise amplifier, and power amplifier. Transmit power is 5 W saturated, receiver noise figure is 2.2 dB. Lead free and RoHS compliant.
Key Features
- Frequency Range: 8.5 – 10.5 GHz
- Tx Psat: 32.5 dBm
- Rx NF: 2.1 dB
Key Applications
- Communications
- Commercial and Military Radar
QPF5002 is a multi-die front-end module (FEM) designed for 8.5 – 10.5 GHz X-Band applications. The FEM integrates T/R switch, limiter, low-noise amplifier, and power amplifier. Transmit power is 2 W saturated, receiver noise figure is 2.1 dB. Lead free and RoHS compliant.
Key Features
- Frequency Range: 5 – 6 GHz
- PSAT: 47 dBm
Key Applications
- Electronic Warfare
- Radar
Key Features
- Operating Frequency Range: 3.1 – 3.5 GHz
- Saturated Output Power PSAT: 51dBm
- Power Added Efficiency at PSAT: 62%
- Large Signal Gain at PSAT: 30.4 dB
- Bias: VDS1,2=+50V, IDQ1=36mA, IDQ2=192mA
- Package Type: SMD
- Package Dimensions: 25.0 x 12.5 x 3.488 mm
Key Applications
- Military Radar
- Commercial Radar
The QPA2513 is a 2-stage S-Band internally matched GaN Power Amplifier Module. The QPA2513 operates at pulsed RF CW in frequency range 3.1 -3.5 GHz providing typically 51dBm of saturated output power with 30dB of large-signal gain and 62% of power added efficiency. The QPA2513 is matched to 50 Ohms with integrated bias circuits and DC blocking capacitor at input port. The QPA2513 in a SMD package that provides good thermal properties and ideal for use in both commercial and military radar systems. Lead free and RoHS compliant.
