Intended for radar and 5G phased array applications
LaFox, IL, Wednesday, January 13, 2016 – Richardson Electronics, Ltd. (NASDAQ: RELL) announced today the availability of a new X-band silicon quad-core integrated circuit from Anokiwave, Inc.
The highly-integrated AWS-0101 is intended for radar and 5G phased array applications. The device supports four radiating elements, single-beam transmit and dual-beam receive, and includes all requisite beam-steering controls for 6-bit phase and gain control. It provides 21 dB gain during transmit mode, 21 dB gain in receive mode, +15 dBm output power during transmit, and 3.4 dB noise figure during receive. Additional features include gain compensation over temperature, temperature reporting, and fast beam-switching using eight on-chip beam weight storage registers.
The new IC offers ESD protection on all pins, operates from +1.8 V, and is packaged in a 56-lead, 7 mm x 7 mm PQFN for easy installation in planar phased array antennas.
“The AWS-0101 enables a complete silicon RF solution for commercial AESA, with reduced system size, weight and cost,” said Chris Marshall, CTO and VP Marketing of Richardson Electronics’ Power & Microwave Technologies group. “It is another example of how Anokiwave is opening the door for new possibilities in phased array applications.” Additional key features of the AWS-0101 include:
- -16 dBm Rx IIP3
- 6 bit phase control (LSB=5.625°)
- 6 bit gain control (LSB=0.5dB)
- 8 W DC Tx mode
- 8 W DC Rx mode
To find more information, please visit the AWS-0101 product detail page at www.rellpower.com. The device is also available by calling 1-800-348-5580, emailing [email protected], or visiting Local Sales Support to locate worldwide sales engineers. To learn about additional Anokiwave products, please visit the Anokiwave storefront. Playback of an Anokiwave webinar, “Highly Integrated Silicon ICs – A Disruptive Technology for Phased Arrays,” is also available online until March 30, 2016.
